PA-32PL-28-1
  • PA-32PL-28-1
  • PA-32PL-28-1

PA-32PL-28-1

£70.00

Programming & test package adapter for 1.27mm pitch J-lead PLCC Memory devices up to 512kbits with 32 pins.

Maps to a standard 28-pin Dual In-line Pin-out (DIP) - 0.1” (2.54mm) pitch 0.6” wide

SKU : PA32PL28-1

Programming & test package adapter for 1.27mm pitch J-lead PLCC Memory devices up to 512kbits with 32 pins.

Maps to a standard 28-pin Dual In-line Pin-out (DIP) - 0.1” (2.54mm) pitch 0.6” wide

The open-type push/pop Zero-Insertion Force (ZIF) socket allows easy insertion and removal of devices.

The adapter is for use on any programming or test equipment.

Example Devices:

256K & 512Kbit EPROM, EEPROM & Flash memory devices in 32-pin PLCC package

Notes

  1. The adapter uses an IC120 series open-type push/pop Zero-Insertion Force (ZIF) socket from Yamaichi, with two-point contacts (Socket code: IC120-0324-309)
  2. It has a life cycle of 10,000 insertion cycles (minimum) under normal use.
  3. Operating temperature range: -40°C ~ +170°C
  4. Printed circuit board material: RF4 with 1 Once copper with a Nickel/Gold RoHS compliant finish
  5. Adapter is Lead-free and RoHS compliant
